Warning signs on a Range Rover or Land Rover
- “Suspension fault, normal height only” or “Max speed 35 mph” on the dash
- The car sits low at one corner when you come out in the morning, then rises after start-up
- Access height or off-road height will not engage, or Terrain Response limits the modes you can pick
- The compressor runs for a long time, or you hear it cycle again soon after you park
- The car leans side to side or front to back on level ground
- A hiss from a wheel arch after you switch the engine off
Take a photo of the dash message when it appears. It helps us read the stored fault faster.
How Land Rover electronic air suspension works
Land Rover calls the system EAS, electronic air suspension. Each corner rides on air instead of a steel coil. At the front, most models use an air strut that combines the air spring and the shock absorber in one unit. A compressor fills a reservoir, a valve block sends air to each corner, and four height sensors report to the air suspension module. The module adjusts each corner many times a minute to keep the car level, lower it for access and raise it for wading or off-road driving.
That constant adjustment is why a small leak becomes a big job. The compressor has a duty limit. When it runs past that limit to make up for a leaking strut, it overheats, wears its piston seal and can take its relay with it.
Range Rover models and what fails most
| Model | Years | Common air suspension faults |
|---|---|---|
| Range Rover (L322) | 2003–2012 | Front air struts, rear air springs, compressor wear, valve block leaks |
| Range Rover Sport (L320) and LR3 / LR4 | 2005–2016 | Air springs, compressor, cracked air lines, height sensor faults |
| Range Rover (L405) and Range Rover Sport (L494) | 2013–2022 | Front air struts, rear air springs, compressor and reservoir |
| Velar and Discovery (L462), where air suspension is fitted | 2017 on | Front air struts, compressor, height sensor calibration |
| Range Rover (L460) and Sport (L461) | 2022 on | Air strut leaks, software and height calibration after other repairs |
The Evoque and Discovery Sport ride on steel springs, so their suspension work is covered on our Range Rover repair page.
How we test before we replace anything
- Pathfinder-level scan. We read the air suspension module for stored and current faults, live height values at each corner, reservoir pressure and compressor temperature.
- Overnight drop check. When the car only sags after sitting, we record each corner’s height and check it again after the car has been parked. The corner that drops is the corner that leaks.
- Leak test. We pressurize the system and test each strut, spring, line and fitting, plus the valve block, with leak spray or an electronic detector.
- Compressor test. We time how long it takes to raise the car from its lowest height and check the compressor relay and fuse.
- Photos and a written estimate. You see the cracked bellows, the wet fitting or the slow compressor time on your phone before you approve.
- Repair, height calibration and road test. After the repair we calibrate ride height with the Land Rover procedure, clear the faults and drive the car through every height mode.
Parts choices, explained plainly
Air struts and springs come as genuine Land Rover parts and as aftermarket units from established suspension makers. We show you which options exist for your model and the warranty on each, and we never fit a part you have not approved. If the matching strut on the other side shows the same cracking, we photograph it and let you decide whether to replace the pair.
Broward conditions that age air suspension
Range Rovers here spend long hours parked on hot asphalt and in sun-baked garages. Rubber bellows that never cool down dry out and crack along their folds. Summer humidity loads the air dryer, and moisture that gets past it corrodes the valve block from the inside. Owners near the beach on A1A, in Lauderdale-by-the-Sea or along the Intracoastal also see salt corrosion on the metal crimp rings that seal each strut. Seasonal owners who leave a Range Rover parked for months often see the first sag the week they return.
Bringing in a car that sits too low
If your Range Rover is on its bump stops, do not drive it far. The tires can rub the arches and the compressor will keep running. Call the shop to schedule pickup with our concierge service. You can also use after-hours drop-off at Oakland Park, where the lot is open 24 hours and keys go in the drop box at the front door, and we call you in the morning.
